An Innovation Eye Protection Modular Panel Light Customizable Module Length & Panel Dimensions Low Glare Reflector with Lens solution Beam Angle: 65°/UGR16, 90° /UGR19 optional Luminous efficiency up to 140lm/W Standard size: 600x600mm, 620x620mm, 300x1200mm, 300x1500mm, 600x1200mm . Non-standard dimensions can be customized Light source : Lumileds SMD2835, CRI>80Ra, >90Ra Functions: On/Off, 1-10V, DALI-2, Sensor, Emergency etc. Product finish: White (Standard) , Black Reflectors color: White, Black, silver(electroplating), Clear optional
Customizable LED Module & Panel Lighting
Skyled series of LED module panel lights feature customizable models that offer enhanced flexibility and a seamless lighting experience.
This design innovation fulfills functional needs while prioritizing aesthetic precision.
The adjustable module length distinguishes the series by offering a customize, gap-free lighting solution that integrates seamlessly with diverse design requirements.
Skyled series Modular led panel light series offer 65° and 90° beam angles, suitable for various application spaces. Each light features a lens combined with reflectors.
Color Options: white, black, silver, and transparent colors.
Common sizes : 595x595mm | 295x1195mm | 620x620mm | 295x1495mm | 595x1195mm etc.
We can customize the dimension according to your project requirements.
Customized installation
An Innovation Eye Protection Modular Panel Light Customizable Module Length & Panel Dimensions
- Low Glare Reflector with Lens solution Beam Angle: 65°/UGR16, 90° /UGR19 optional
- Luminous efficiency up to 140lm/W
- Standard size: 600x600mm, 620x620mm, 300x1200mm, 300x1500mm, 600x1200mm .
- Non-standard dimensions can be customized Light source : Lumileds SMD2835, CRI>80Ra, >90Ra
- Functions: On/Off, 1-10V, DALI-2, Sensor, Emergency etc.
- Product finish: White (Standard) , Black Reflectors color: White, Black, silver(electroplating), Clear optional
| Model No.: | Dimension | Power | Color Temperature | Luminous Efficacy | Lumen | CRI |
| LM-MP30W-6060B | 600x600mm
Actual size(595x595mm ) |
30W | 6000-6500K
5000-5500K 4000-4500K 2800-3500K CCT change option |
>140lm/W | 4200lm | >80Ra |
| LM-MP30W-30120B | 300x1200mm
Actual size(295x1195mm ) |
30W | >140lm/W | 4200lm | >80Ra | |
| LM-MP30W-6262B | 620x620mm
Actual size(620x620mm ) |
30W | >140lm/W | 4200lm | >80Ra | |
| LM-MP60W-60120B | 600x1200mm
Actual size(595x1195mm ) |
60W | >140lm/W | 8400lm | >80Ra |
